Eti CH 10/14x85 T gPV 50A/1500V

• ETI Code:: 002626240
• Description:: CH 10/14x85 T gPV 50A/1500V
• Class name:: Fuse link
• efuse:: 1
• Type:: CH
• Size:: 10/14x85
• Rated current (A):: 50
• Rated DC voltage (V):: 1500
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 50
• Application:: For protection of photovoltaic modules
• Power dissipation (0,7x In) (W):: 5,3
• Power dissipation (W):: 13
• Operating joule integral (A2s):: 2.000
• Prearcing joule integral (A2s):: 350
• Standards:: IEC 60269-6, UL 248-19
• UL certificate:: E347771
