Eti CH10/14x85 gPV 25A/1500V

• ETI Code:: 002626235
• Description:: CH10/14x85 gPV 25A/1500V
• Class name:: Fuse link
• efuse:: 1
• Type:: CH
• Size:: 10/14x85
• Rated current (A):: 25
• Rated DC voltage (V):: 1500
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 50
• Application:: For protection of photovoltaic modules
• Indicator:: Without
• Power dissipation (0,7x In) (W):: 2,3
• Power dissipation (W):: 5,6
• Operating joule integral (A2s):: 633,1
• Prearcing joule integral (A2s):: 72,3
• Standards:: IEC 60269-6, UL 248-19
• UL certificate:: E347771
