Eti CH10x85 IN gPV 6A/1500V

• ETI Code:: 002626304
• Description:: CH10x85 IN gPV 6A/1500V
• Class name:: Fuse link
• Type:: CH-IN
• Size:: 10x85
• Rated current (A):: 6
• Rated DC voltage (V):: 1500
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 50
• Application:: For protection of photovoltaic modules
• Power dissipation (0,7x In) (W):: 1,2
• Power dissipation (W):: 3
• Operating joule integral (A2s):: 50,6
• Prearcing joule integral (A2s):: 14,5
• Standards:: IEC 60269-6
