Eti CH10x85gPV 25A 1200V UL

• ETI Code:: 002625208
• Description:: *CH10x85gPV 25A 1200V UL
• Class name:: Fuse link
• Type:: CH
• Size:: 10x85
• Rated current (A):: 25
• Rated DC voltage (V):: 1200
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 10
• Application:: For protection of photovoltaic modules
• Power dissipation (0,7x In) (W):: 2,1
• Power dissipation (W):: 5,2
• Operating joule integral (A2s):: 504
• Prearcing joule integral (A2s):: 72
• Standards:: IEC 60269-6, UL 2579, UL 248-1
• UL certificate:: E347771
