Eti NH00 100A/440V DC

• ETI Code:: 004110212
• Description:: NH00 100A/440V DC
• Class name:: Fuse link
• efuse:: 1
• Type:: NH
• Size:: NH00
• Rated current (A):: 100
• Rated DC voltage (V):: 440
• Characteristics:: gR
• L/R (ms):: 20
• Breaking capacity DC (kA):: 50
• Application:: Fuse link for DC application
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 12,2
• Operating joule integral (A2s):: 16.848
• Prearcing joule integral (A2s):: 9.360
• Standards:: IEC 60269-2
