Eti NH1C 125A/440V DC

• ETI Code:: 004110228
• Description:: NH1C 125A/440V DC
• Class name:: Fuse link
• efuse:: 1
• Type:: NH
• Size:: NH1C
• Rated current (A):: 125
• Rated DC voltage (V):: 440
• Characteristics:: gR
• L/R (ms):: 20
• Breaking capacity DC (kA):: 50
• Application:: Fuse link for DC application
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 15,5
• Operating joule integral (A2s):: 26.550
• Prearcing joule integral (A2s):: 14.750
• Standards:: IEC 60269-2
