Eti NH1XL gR 100A/1100V DC

• ETI Code:: 004110542
• Description:: NH1XL gR 100A/1100V DC
• Class name:: Fuse link
• efuse:: 1
• Designed for:: Protection of PV installations
• Product subgroup:: PV
• Product group:: Special purpose fuses
• L/R (ms):: 5
• Type:: NH
• Size:: NH1XL
• Rated current (A):: 100
• Rated DC voltage (V):: 1100
• Characteristics:: gR
• Breaking capacity DC (kA):: 10
• Application:: Fuse link for DC application
• Indicator:: Top fuse status indicator
• Power dissipation (0,7x In) (W):: 8,2
• Power dissipation (W):: 20
• Prearcing joule integral (A2s):: 6.500
• Operating joule integral (A2s):: 9.000
• Standards:: IEC 60269-4
