Eti NH3L/K gR 315A/1100V DC

• ETI Code:: 004110557
• Description:: NH3L/K gR 315A/1100V DC
• Class name:: Fuse link
• Designed for:: Protection of PV installations
• Product subgroup:: PV
• Product group:: Special purpose fuses
• L/R (ms):: 5
• Type:: NH-K
• Size:: NH3L
• Rated current (A):: 315
• Rated DC voltage (V):: 1100
• Characteristics:: gR
• Breaking capacity DC (kA):: 10
• Application:: Fuse link for DC application
• Indicator:: Striker pin status indicator
• Power dissipation (0,7x In) (W):: 25,2
• Power dissipation (W):: 54
• Prearcing joule integral (A2s):: 166.800
• Operating joule integral (A2s):: 221.900
• Standards:: IEC 60269-4
