Eti NHG1 gR 160A/1000V DC

• ETI Code:: 004303530
• Description:: NHG1 gR 160A/1000V DC
• Class name:: Fuse link
• efuse:: 1
• Size:: NH1
• Type:: NH-G
• Rated current (A):: 160
• Rated DC voltage (V):: 1000
• Characteristics:: gR
• L/R (ms):: 10
• Breaking capacity DC (kA):: 30
• Application:: Railway inverter protection
• Indicator:: Centre trip indicator for MK+AMK2
• Power dissipation (0,7x In) (W):: 15,3
• Power dissipation (W):: 36,5
• Operating joule integral (A2s):: 16.000
• Prearcing joule integral (A2s):: 10.000
• Standards:: IEC 60269-4
