Eti NHG1/M gR 200A/1000V DC

• ETI Code:: 004303528
• Description:: NHG1/M gR 200A/1000V DC
• Class name:: Fuse link
• Size:: NH1
• Type:: NH-G
• Rated current (A):: 200
• Rated DC voltage (V):: 1000
• Characteristics:: gR
• L/R (ms):: 10
• Breaking capacity DC (kA):: 30
• Application:: Railway inverter protection
• Indicator:: Centre trip indicator for MK
• Power dissipation (0,7x In) (W):: 17,5
• Power dissipation (W):: 42,6
• Operating joule integral (A2s):: 38.000
• Prearcing joule integral (A2s):: 18.000
• Standards:: IEC 60269-4
