Eti NHS2/394/M aR 200A/4000V DC

• ETI Code:: 004735604
• Description:: NHS2/394/M aR 200A/4000V DC
• Class name:: Fuse link
• efuse:: 1
• Size:: NH2
• Type:: NH-S
• Rated current (A):: 200
• Rated DC voltage (V):: 4000
• Characteristics:: aR
• L/R (ms):: 15
• Breaking capacity DC (kA):: 30
• Application:: Fuse link for DC link protection of railway inver
• Dimensions:: S394mm
• Indicator:: Centre trip indicator for MK
• Power dissipation (W):: 127
• Operating joule integral (A2s):: 100.000
• Prearcing joule integral (A2s):: 10.000
• Standards:: IEC 60269-4 , IEC 60077-5
