Eti NHS2XL gPV 200A/1100V DC UL

• ETI Code:: 004110478
• Description:: NHS2XL gPV 200A/1100V DC UL
• Class name:: Fuse link
• Type:: NH-S
• Size:: 2XL
• Rated current (A):: 200
• Rated DC voltage (V):: 1100
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 10
• Application:: Fuse link for DC application
• Dimensions:: S170mm
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 36
• Power dissipation (0,7x In) (W):: 15,9
• Operating joule integral (A2s):: 75.000
• Prearcing joule integral (A2s):: 55.000
• Standards:: IEC 60269-6, UL 248-19
• UL certificate:: E347771
