Eti NHS3L/MS gPV 315A/1500V DC UL

• ETI Code:: 004110729
• Description:: NHS3L/MS gPV 315A/1500V DC UL
• Class name:: Fuse link
• Type:: NH-S
• Size:: 3L
• Rated current (A):: 315
• Rated DC voltage (V):: 1500
• Characteristics:: gPV
• L/R (ms):: 3
• Breaking capacity DC (kA):: 50
• Application:: Fuse link for DC application
• Dimensions:: S170mm
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 57
• Power dissipation (0,7x In) (W):: 22,2
• Operating joule integral (A2s):: 300.000
• Prearcing joule integral (A2s):: 65.000
• Standards:: IEC 60269-6, UL 248-19
