Eti NHU1XL gPV 200A/1500V DC UL

• ETI Code:: 004110611
• Description:: NHU1XL gPV 200A/1500V DC UL
• Class name:: Fuse link
• Type:: NH-U
• Size:: 1XL
• Rated current (A):: 200
• Rated DC voltage (V):: 1500
• Characteristics:: gPV
• L/R (ms):: 3
• Breaking capacity DC (kA):: 30
• Application:: Fuse link for DC application
• Dimensions:: U170mm
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 32,5
• Power dissipation (0,7x In) (W):: 13,7
• Operating joule integral (A2s):: 75.000
• Prearcing joule integral (A2s):: 22.000
• Standards:: IEC 60269-6, UL 248-19
• UL certificate:: E347771
