Eti NHU1XL gPV 63A/1100V DC UL

• ETI Code:: 004110487
• Description:: NHU1XL gPV 63A/1100V DC UL
• Class name:: Fuse link
• Type:: NH-U
• Size:: 1XL
• Rated current (A):: 63
• Rated DC voltage (V):: 1100
• Characteristics:: gPV
• L/R (ms):: 2
• Breaking capacity DC (kA):: 10
• Application:: Fuse link for DC application
• Dimensions:: U170mm
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 15,7
• Power dissipation (0,7x In) (W):: 7
• Operating joule integral (A2s):: 3.500
• Prearcing joule integral (A2s):: 2.800
• Standards:: IEC 60269-6, UL 248-19
• UL certificate:: E347771
