Eti NHU2 gPV 200A/1000V DC

• ETI Code:: 004110296
• Description:: NHU2 gPV 200A/1000V DC
• Class name:: Fuse link
• Type:: NH-U
• Size:: NH2
• Rated current (A):: 200
• Rated DC voltage (V):: 1000
• Characteristics:: gPV
• L/R (ms):: 1
• Breaking capacity DC (kA):: 30
• Application:: Fuse link for DC application
• Dimensions:: U110mm
• Indicator:: Top fuse status indicator
• Power dissipation (W):: 26
• Power dissipation (0,7x In) (W):: 11
• Operating joule integral (A2s):: 29.000
• Prearcing joule integral (A2s):: 4.400
• Standards:: IEC 60269-6

PDF 1 - Teknik Doküman
PDF 2 - Ürün Çizimi
