Eti NHU3L gBat 315A/1500V DC

• ETI Code:: 004110687
• Description:: NHU3L gBat 315A/1500V DC
• Class name:: Fuse link
• Rated current (A):: 315
• Type:: NH-U
• Size:: 3L
• Characteristics:: gBat
• Rated DC voltage (V):: 1500
• Dimensions:: U170mm
• Indicator:: Top fuse status indicator
• Breaking capacity DC (kA):: 100
• Operating joule integral (A2s):: 350.000
• L/R (ms):: 3
• Prearcing joule integral (A2s):: 60.000
• Application:: Battery protection
• Power dissipation (W):: 57
• Power dissipation (0,7x In) (W):: 22,2
• Standards:: IEC 60269-7
