- ETI Code:: 004110737
- Description:: NHU3L/MS gPV 450A/1500V DC UL
- Class name:: Fuse link
- Type:: NH-U
- Size:: 3L
- Rated current (A):: 450
- Rated DC voltage (V):: 1500
- Characteristics:: gPV
- L/R (ms):: 3
- Breaking capacity DC (kA):: 50
- Application:: Fuse link for DC application
- Dimensions:: U170mm
- Indicator:: Top fuse status indicator
- Power dissipation (W):: 75
- Power dissipation (0,7x In) (W):: 29
- Operating joule integral (A2s):: 600.000
- Prearcing joule integral (A2s):: 130.000
- Standards:: IEC 60269-6, UL 248-19
